LED Wall Packs

No.:WK06
Replacing metal halide fixtures with WK06 series LED wall pack increases energy e ciency and lowers maint enance costs. Rugged die-cast aluminum Heat dissipation , while durable PC lens is UV-stabilized to withstand conditions of outdoor industrial or commercial locations.
Power:
20W, 30W, 40W, 60W, 80W, 100W, 120W Selectable
Color:
3000/4000/5000K Selectable
Voltage:
AC120-277V
LEDs:
SMD2538, Ra>80
Efficacy:
120LPW
Driver:
PF>0.9
IP Rate:
IP65, Wet Location
Certificate:
UL, DLC
Warranty:
5 Years
  • LED Wall Packs
  • LED Wall Packs
  • LED Wall Packs
  • LED Wall Packs

Description

Replacing metal halide fixtures with WK06 series LED wall pack increases energy e ciency and lowers maint enance costs. Rugged die-cast aluminum Heat dissipation , while durable PC lens is UV-stabilized to withstand conditions of outdoor industrial or commercial locations.

A variety of drivers are available

Using a non-isolated driver, 0-10V dimmable.

Protection level: Wet Location

The Wall Pack is sealed by silicone ring that can avoid dust completely and be waterproof, the internal level  ensures that the installation is horizontal too.

277-480VAC available. Power tunable and CCT switchable available.
